SERGIO SOLUTION CO.,LTD.

Image Sensor      : 2 MP CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.01 lux@F2.0 (Color, 30 IRE), 0.001 lux@F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : IR: 20 m (65.62 ft), Warm light: 20 m (65.62 ft)
Illuminator On/Off Control      : Auto
lIlluminator Number      : 1 (Warm light);1 (IR light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Auto Focus      : No
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F2.0
Field of View      : 2.8 mm: H: 102.°; V: 60°; D: 129°, 3.6 mm: H: 83°; V: 48°; D: 105°
Close Focus Distance      : 2.8 mm: 0.5 m (1.64 ft), 3.6 mm: 0.7 m (2.30 ft)
DORI Distance      : Lens 2.8mm, Detect:41.1m(135.83 ft), Observe: 16.5m(42.13 ft), Recognize: 8.3m(27.23 ft), Identify: 4.1m(13.45 ft) / Lens 3.6mm, Detect:50.9m(166.99ft), Observe: 20.3m(66.60 ft), Recognize: 10.2m(33.46 ft), Identify: 5.1m(16.73 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;, PAL: 960H;, NTSC: 960H
Resolution      : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; DWDR
WDR      : DWDR
White Balance      : Auto;Area white balance
Gain Control      : Auto
Noise Reduction      : 3D NR
Illumination Mode      : Smart IR&WL; WL Mode; IR Mode
Mirror      : Yes
Pick-up Distance      : Off/On (8 areas, rectangle)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;, FCC: 47 CFR FCC Part 15, Subpart B;, UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input      : 1 Channel

Power Supply      : 12 VDC (±30%)
Power Consumption       : Max 2.6 W (12 VDC, IR on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67

Casing Material      : Metal
Product Dimensions      : 166.6 mm × 69.7 mm × 70.0 mm (6.56″ × 2.74″ × 2.76″) (L×W×H)
Net Weight      : 0.32 kg (0.71 lb)
Gross Weight      : 0.40 kg (0.88 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
