Image Sensor      : 2 MP CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.01 lux@F2.0 (Color, 30 IRE), 0.001 lux@F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dBI
llumination Distance      : 40 m (131.23 ft)
Illuminator On/Off Control      : Auto/Manual
lIlluminator Number      : 4 (Multi-core light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F2.0
Field of View      : 2.8 mm: H: 111.3°; V: 60.8°; D: 134.2°, 3.6 mm: H: 89°; V: 48.2°; D: 109.1°
Close Focus Distance      : 2.8 mm: 0.5 m (1.64 ft), 3.6 mm: 0.7 m (2.30 ft)
DORI Distance      : Lens 2.8mm, Detect:40.6m(133.20 ft), Observe: 16.2m(53.15 ft), Recognize: 8.1m(26.57 ft), Identify: 4.1m(13.45 ft) / Lens 3.6mm, Detect:49.9m(163.71ft), Observe: 20.0m(65.62 ft), Recognize: 10.0m(32.81 ft), Identify: 5.0m(16.40 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;, PAL: 960H;, NTSC: 960H
Resolution      : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; WDR; HLC-Pro
WDR      : DWDR
White Balance      : Auto
Gain Control      : Manual;Auto
Noise Reduction      : 3D NR
Illumination Mode      : Smart IR&WL (CVI, TVI); WL Mode; IR Mode
Mirror      : Yes
Pick-up Distance      : 8 m (26.25 ft)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes, up to 8 m (26.25 ft)
Camera Audio      : CVI; TVI
Two-way Talk      : Yes (CVI, TVI)
Speaker      : Yes, up to 8 m (26.25 ft)

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%) (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption       : Max 9.37 W (12 VDC, IR on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67
Anti-corrosion Level      : Basic Protection

Casing Material      : Metal front cover + plastic rear barrel + metal bracket
Product Dimensions      : 198.4 mm × 80.2 mm × 76.2 mm (7.81″ × 3.16″ × 3.00″) (L×W×H)
Net Weight      : 0.34 kg (0.75 lb)
Gross Weight      : 0.49 kg (1.08 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
