Image Sensor      : 2 MP CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.0001 lux@F1.0 (Color, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dBI
llumination Distance      : 50 m (164.04 ft)
Illuminator On/Off Control      : Auto
lIlluminator Number      :  4 (Warm light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.0
Field of View      : 2.8 mm: H: 101°; V: 53.4°; D: 119.5°, 3.6 mm: H: 81.5°; V: 44.3°; D: 95.7°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 47.1m(154.53 ft), 3.6 mm: 1.7 m (5.58 ft)
DORI Distance      : Lens 2.8mm, Detect:45.6m(149.61 ft), Observe: 18.9m(62.01 ft), Recognize: 9.4m(30.84 ft), Identify: 4.7m(15.42 ft) / Lens 3.6mm, Detect: 55.7m(182.74 ft), Observe: 22.3m(73.16 ft), Recognize: 11.1m (36.42 ft), Identify: 5.6 m(18.37 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;, PAL: 960H;, NTSC: 960H
Resolution      : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto      : Color
BLC      : BLC; HLC; WDR
WDR      : 130 dB
White Balance      : Auto
Gain Control      : Auto
Noise Reduction      : 3D NR
Motion Detection      : Yes (It needs to be controlled through the XVR)
Illumination Mode      : Smart Light
Mirror      : Yes (It needs to be controlled through the XVR)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes, built-in dual Mic
Camera Audio      : CVI
Pick-up Distance      : 12 m (39.37 ft)

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%)Power
Consumption       : Max 5.6 W (12 VDC, LED on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67
Anti-corrosion Level      : Basic Protection

Casing Material      : Metal front cover + plastic rear barrel + metal bracket
Product Dimensions      : 186.5 mm × 75 mm × 82.2 mm (7.34″ × 2.95″ × 3.24″) (L×W× )
Net Weight      : 0.35 kg (0.77 lb)
Gross Weight      : 0.49 kg (1.08 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
