Image Sensor      : 5 MP CMOS
Max. Resolution      : 2880 (H) × 1620 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.05 lux@F1.6 (Color, 30 IRE), 0.005 lux@F1.6 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : IR: 20 m (65.62 ft), Warm light: 20 m (65.62 ft)
Illuminator On/Off Control      : Auto/Manual
lIlluminator Number      : 1 (Warm light);1 (IR light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.6
Field of View      : 2.8 mm: H: 106°; V: 56°; D: 125°, 3.6 mm: H: 92°; V: 48°; D: 109°
Close Focus Distance      : 2.8 mm: 0.8 m (2.62 ft), 3.6 mm: 1.3 m (4.27 ft)
DORI Distance      : Lens 2.8mm, Detect:56.1m(183.73 ft), Observe: 22.4m(73.49 ft), Recognize:11.2m(36.75 ft), Identify: 5.6m(18.37 ft) / Lens 3.6mm, Detect:76m(249. ft), Observe: 30.4m(99.74 ft), Recognize: 15.2m(49.87 ft), Identify: 7.6m(24.93 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps;, NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps, PAL: 4M@25 fps;, NTSC: 4M@30 fps, PAL: 4M@25 fps;, NTSC: 4M@30 fps, PAL: 960H;, NTSC: 960H
Resolution      : 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; DWDR
WDR      : DWDR
White Balance      : Auto;Area white balance
Gain Control      : Auto/Manual
Noise Reduction      : 2D NR
Illumination Mode      : Smart IR&WL; WL Mode; IR Mode
Mirror      : Yes
Pick-up Distance      : Off/On (8 areas, rectangle)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;, FCC: 47 CFR FCC Part 15, Subpart B;, UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input      : One channel built-in mic

Power Supply      : 12 VDC (±30%)
Power Consumption       : Max 3.1 W (12 VDC, IR on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67

Casing Material      : Metal
Product Dimensions      : 166.6 mm × 69.7 mm × 70.0 mm (6.56″ × 2.74″ × 2.76″) (L×W×H)
Net Weight      : 0.33 kg (0.73 lb)
Gross Weight      : 0.41 kg (0.90 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
