Image Sensor      : 5 MP CMOS
Max. Resolution      : 2880 (H) × 1620 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.01 lux@F1.6 (Color, 30 IRE), 0.001 lux@F1.6 (B/W, 30 IRE), 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : IR: 30 m (98.43 ft), Warm Light: 30 m (98.43 ft)
Illuminator On/Off Control      : Auto
lIlluminator Number      : 2 (Multi-core light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Auto Focus      : No
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.6
Field of View      : 2.8 mm: H: 113.3°; V: 62.1°; D: 134.3°, 3.6 mm: H: 90.1°; V: 47.8°; D: 109.3°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 0.8 m (2.62 ft), 3.6 mm: 1.3 m (4.27 ft)
DORI Distance      : Lens 2.8mm, Detect:59.8m(196.19 ft), Observe: 23.9m(78.41 ft), Recognize:12.2m(39.37 ft), Identify: 6.0m(19.69 ft) / Lens 3.6mm, Detect:77m(252.62 ft), Observe: 30.8m(101.05 ft), Recognize: 15.4m(50.52 ft), Identify: 7.7m(25.26 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps;, NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps, PAL: 4M@25 fps;, NTSC: 4M@30 fps, PAL: 4M@25 fps;, NTSC: 4M@30 fps, PAL: 960H;, NTSC: 960H
Resolution      : 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480); TVI 5M 16:9 (2960 × 1665)
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; DWDR
WDR      : DWDR
White Balance      : Auto;Area white balance
Gain Control      : Auto
Noise Reduction      : 3D NR
Motion Detection     : Yes
Illumination Mode      : Smart IR&WL; WL Mode; IR Mode
Mirror      : Yes
Privacy Masking      : Off/On (8 areas, rectangle)
Pick-up Distance      : 8 m (26.25 ft)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes
Camera Audio      : CVI; TVI

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%)
Power Consumption       : Max 4.3 W (12 VDC, WLED on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67
Anti-corrosion Level      : Basic Protection

Casing Material      : Metal
Product Dimensions      : 166.4 mm × 69.7 mm × 70.0 mm (6.55″ × 2.74″ × 2.75″) (L × W × H)
Net Weight      : 0.35 kg (0.77 lb)
Gross Weight      : 0.45 kg (0.99 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
