Image Sensor      : 5 MP CMOS
Max. Resolution      : 2880 (H) × 1620 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.001 lux@F1.0 (Color, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : Warm light: 50 m (164.04 ft)
Illuminator On/Off Control      : Auto/Manual
lIlluminator Number      : 4 (Warm light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.0
Field of View      : 2.8 mm: H: 109.6°; V: 57.5°; D: 131°, 3.6 mm: H: 88.2°; V: 47.6°; D: 104.5°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 2.0 m (6.56 ft), 3.6 mm: 3.0 m (9.84 ft)
DORI Distance      : Lens 2.8mm, Detect: 66.0m(216.65 ft), Observe: 26.4m(86.61 ft), Recognize: 13.2m(43.31 ft), Identify: 6.6m(21.65 ft) / Lens 3.6mm, Detect: 78.0m(255.91ft), Observe: 31.2m(102.36 ft), Recognize: 15.6m(51.18 ft), Identify: 7.8m(25.59 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 5M@25 fps; 5M@12.5 fps;, NTSC: 5M@25 fps; 5M@10 fps;, PAL: 4M@25 fps, NTSC: 4M@30 fps, PAL: 5M@20 fps, NTSC: 5M@20 fps, PAL: 960H, NTSC: 960H
Resolution      : 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480); TVI 5M 16:9 (2960 × 1665)
Day/NightAuto      : Color
WDR      : 130 dB
White Balance      : Auto
Gain Control      : Auto
Noise Reduction      : 3D NR
Motion Detection      : Yes (It needs to be controlled through the XVR)
Illumination Mode      : Smart Light
Mirror      : Yes (It needs to be controlled through the XVR)

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes, built-in dual Mic
Camera Audio      : CVI
Pick-up Distance      : 12 m (39.37 ft)

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%)
Power Consumption       : Max 5.8 W (12 VDC, LED on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67
Anti-corrosion Level          : Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection

Casing Material      : Metal front cover + plastic rear barrel + metal bracket
Product Dimensions      : 186.5 mm × 75 mm × 82.2 mm (7.34″ × 2.95″ × 3.24″) (L×W×H)
Net Weight      : 0.35 kg (0.77 lb)
Gross Weight      : 0.49 kg (1.08 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
