Image Sensor      : 2 MP CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.01 lux@F2.0 (Color, 30 IRE), 0.001 lux@F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : IR: 50 m (164.04 ft), Warm light: 50 m (164.04 ft)
Illuminator On/Off Control      : Auto/Manual
lIlluminator Number      : 4 (Multi-core light)

Lens Type      : Fixed-focal
Auto Focus      : No
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F2.0
Field of View      : 2.8 mm: H: 109°; V: 59.6°; D: 134.2°, 6.0 mm: H: 47.2°; V: 26.2°; D: 54.5°
Close Focus Distance      : 2.8 mm: 0.5 m (1.64 ft), 6.0 mm: 2.3 m (7.55 ft)
DORI Distance      : Lens 2.8mm, Detect:41.4m(135.83 ft), Observe: 16.5m(54.13 ft), Recognize: 8.3m(27.23 ft), Identify: 4.1m(13.45 ft) / Lens 6.0mm, Detect:95.1m(312.01ft), Observe: 38.0m(124.67 ft), Recognize: 19.0m(62.34 ft), Identify: 9.5m(31.17 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;, NTSC: 1080p@30 fps;, PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;, PAL: 960H;, NTSC: 960H
Resolution      : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; DWDR
WDR      : DWDR
White Balance      : Auto; Area white balance
Gain Control      : Auto/Manual
Noise Reduction      : 3D NR
Illumination Mode      : Smart IR&WL (CVI, TVI); WL Mode; IR Mode
Defog      : Electronic defog
Digital Zoom      : 6x
Mirror      : Yes
Privacy Masking     : Off/On (8 areas, rectangle)

Pan/Tilt Range      : Pan: 0°–355°, Tilt: 0°–90° (*Do not manually adjust the angle of the main body or enclosure.
Preset      : 80

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes
Camera Audio      : CVI; TVI

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%) (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption       : Max 5.1 W (12 VDC, IR on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP66
Anti-corrosion Level      : Basic Protection

Casing Material      : Plastic
Product Dimensions      : Φ110.0 mm × 150.0 mm (Φ4.33″ × 5.91″)
Net Weight      : 0.46 kg (1.01 lb)
Gross Weight      : 0.65 kg (1.43 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
