Image Sensor      : 2xCMOS
Max. Resolution      : 2880 (H) × 1620 (V)
Scanning System      : Progressive
Electronic Shutter Speed      : PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
Min.Illumination      : 0.005 lux@F2.0 (Color, 30 IRE), 0.0005 lux@F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >65 dB
llumination Distance      : IR: 50 m (164.04 ft), Warm light: 50 m (164.04 ft)
Illuminator On/Off Control      : Auto
lIlluminator Number      : Fixed Lens: 4 (Multi-core light), PT Lens: 2 (Multi-core light)
Angle Adjustment      : Fixed Lens: Tilt: 5°–10°, PT Lens: Pan: 0°–355°; Tilt: 0°–90°, Bracket: Pan: 0°–326°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : PT Lens: 6 mm, Fixed Lens: 2.8 mm
Max. Aperture      : F2.0
Field of View      : Fixed Lens: H: 111.3°; V: 60.8°; D: 134.2°, PT Lens: H: 48.1°; V: 26.7°; D: 55.5°
Close Focus Distance      : Fixed Lens: 0.5 m (1.64 ft), PT Lens: 2.3 m (7.55 ft), 2.8 mm: 0.5 m (1.64 ft);, 6 mm: 2.3 m (7.55 ft)
Iris Control      : Fixed
DORI Distance      : Lens Fixed Lens, Detect:40.6m(133.20 ft), Observe: 16.2m(53.15 ft), Recognize: 8.1m(26.57 ft), Identify: 4.1m(13.45 ft) / Lens PT Lens, Detect:93.3m(306.10ft), Observe: 37.3m(122.38 ft), Recognize: 18.7m(61.35 ft), Identify: 9.3m(30.51 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video Frame Rate      : PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps, NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps, PAL: 4M@25 fps, NTSC: 4M@30 fps, PAL: 4M@25 fps, NTSC: 4M@30 fps, PAL: 960H, NTSC: 960H
Resolution      : 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night      : Auto(ICR)/Color/B/W
BLC      : BLC; HLC; DWDR
White Balance      : Auto; Area white balance
Gain Control      : Auto
Noise Reduction      : 3D NR
Illumination Mode      : Smart IR&WL (CVI, TVI); WL Mode; IR Mode
Defog      : Electronic defog
Mirror      : Yes
Privacy Masking     : Off/On (8 areas, rectangle)

Pan/Tilt Range      : Pan: 0°–355°, Tilt: 0°–90° (*Do not manually adjust the angle of the main body or enclosure.
Preset      : 40
Linkage Tracking      : Yes

Certifications      : CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035;

Built-in Mic      : Yes
Camera Audio      : CVI; TVI

Video Output      : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power Supply      : 12 VDC (±30%) (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption       : Max 10.1 W (12 VDC, IR on)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP66
Anti-corrosion Level      : Basic Protection

Casing Material      : Plastic
Product Dimensions      : 162.5 mm × 122.6 mm × 218.2 mm (6.40″ × 4.83″ × 8.59″) (L × W × H)
Net Weight      : 0.66 kg (1.46 lb)
Gross Weight      : 1.09 kg (2.40 lb)
Installation      : Wall mount; ceiling mount; vertical pole mount
