Image Sensor      : 1/2.8″ CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
ROM      : 128 MB
RAM      : 128 MB
Scanning System      : Progressive
Electronic Shutter Speed      : Auto/Manual 1/3 s–1/100,000 s
Min.Illumination      : 0.002 lux@F1.6 (Color, 30 IRE), 0.0002 lux@F1.6 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >56 dB
llumination Distance      : up to 30 m (98.43 ft) (IR LED)
Illuminator On/Off Control      : Auto;Manual
lIlluminator Number      : 3 (IR LED)
Angle Adjustment      : Pan: 0°–355°, Tilt: 0°–65°, Rotation: 0°–355°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.6
Field of View      : 2.8 mm: H: 106°; V: 56°; D: 127°, 3.6 mm: H: 88°; V: 44°; D: 105°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 0.7 m (2.30 ft), 3.6 mm: 1.3 m (4.27 ft)
DORI Distance      : Lens 2.8mm, Detect: 43.9m(144.03 ft), Observe: 17.5m(51.41 ft), Recognize: 8.8m(28.87 ft), Identify: 4.4m(14.44 ft) / Lens 3.6mm, Detect: 58.9m(193.24 ft), Observe: 23.6m(77.43 ft), Recognize: 11.8m(38.71 ft), Identify: 5.9m(19.37 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

IVS (Perimeter Protection)      : Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
Smart Search      : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video Compression      : H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec      : Smart H.265+; Smart H.264+
Video Frame Rate      : Main stream: 1920 × 1080@(1–25/30 fps), Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability      : 2 streams
Resolution      : 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control      : CBR/VBR
Video Bit Rate      : H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : Yes
HLC      : Yes
WDR      : 120 dB
White Balance      : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control      : Auto/Manual
Noise Reduction      : 3D NR
Motion Detection      : OFF/ON (4 areas, rectangular)
Region of Interest (RoI)      : Yes (4 areas)
Smart Illumination      : Yes
Smart Dual Light      : Yes
Image Rotation    : 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
Mirror      : Yes
Privacy Masking     : 4 areas

Built-in MIC      : Yes
Audio Compression      : G.711a; G.711Mu; G.726; PCM

Alarm Event      : Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception;

Network Port      : RJ-45 (10/100 Base-T)
SDK and API      : Yes
Network Protocol      : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Registration
Interoperability      : ONVIF (Profile S & Profile T); CGI
User/Host      : 6 (Total bandwidth: 36 M)
Storage      : FTP; SFTP; Micro SD card (support max. 256 GB)
Browser      : IE; Chrome; Firefox
Management Software      : DSS; DMSS
Mobile Client      : iOS;Android
Security      : Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot;Trusted execution; Trusted upgrade

Certifications      : CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14

Power Supply      : 12 VDC/PoE
Power Consumption       : Basic: 1.9 W (12 VDC); 2.5 W (PoE) Max. (ICR + H.265 + WDR + max. Illumination + intelligence on): 4.7 W (12 VDC); 5.6 W (PoE)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95%
Protection      : IP67; IK10

Casing Material      : Metal
Product Dimensions      : 81.0 mm × Φ109.9 mm (3.19″ × Φ4.33″)
Net Weight      : 0.34 kg (0.75 lb)
Gross Weight      : 0.49 kg (1.08 lb)
