Image Sensor      : 1/2.9″ CMOS
Max. Resolution      : 2560 (H) × 1440 (V)
ROM      : 128 MB
RAM      : 128 MB
Scanning System      : Progressive
Electronic Shutter Speed      : Auto/Manual 1/3 s–1/100,000 s
Min.Illumination      : 0.006 lux@F1.6 (Color,30 IRE), 0.0006 lux@F1.6 (B/W,30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >56 dB
llumination Distance      : Up to 30 m (98.43 ft) (IR), Up to 30 m (98.43 ft) (Warm light)
Illuminator On/Off Control      : Auto;Manual
lIlluminator Number      : 1 (IR LED); 1 (Warm light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm
Max. Aperture      : F1.6
Field of View      : 2.8 mm: H: 94°; V: 52°; D: 111°, 3.6 mm: H: 78°; V: 41°; D: 94°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 1.1 m (3.61 ft), 3.6 mm: 1.7 m (5.58 ft)
DORI Distance      : Lens 2.8mm, Detect: 64.0m(209.97 ft), Observe: 25.6m(83.98 ft), Recognize: 12.8m(41.99 ft), Identify: 6.4m(21.00 ft) / Lens 3.6mm, Detect: 85.4m(280.18 ft), Observe: 34.2m(112.20 ft), Recognize: 17.1m(56.10 ft), Identify: 8.5m(27.89 ft)

Human and Vehicle Detection      : Support the classification and accurate detection of human and vehicle
Smart Search      : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video Compression      : H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec      : Smart H.265+; Smart H.264+
Video Frame Rate      : Main stream: 2560 × 1440@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability      : 2 streams
Resolution      : 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×240)
Bit Rate Control      : CBR/VBR
Video Bit Rate      : H.264: 32 kbps–4096 kbps;, H.265: 12 kbps–4096 kbps
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : Yes
HLC      : Yes
WDR      : 120 dB
White Balance      : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control      : Auto/Manual
Noise Reduction      : 3D NR
Motion Detection      : OFF/ON (4 areas, rectangular)
Region of Interest (RoI)      : Yes (4 areas)
Smart Illumination      : Yes
Smart Dual Light      : Yes
Image Rotation    : 0°/180°
Mirror      : Yes
Privacy Masking     : 4 areas

Built-in MIC      : Yes, built-in Mic
Audio Compression      : G.711a; G.711Mu; PCM; G.726

Alarm Event      : Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human and vehicle); security exception

Network Port      : RJ-45 (10/100 Base-T)
SDK and API      : Yes
Network Protocol      : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Registration
Interoperability      : ONVIF (Profile S & Profile T); CGI
User/Host      : 6 (Total bandwidth: 24 M)
Storage      : FTP
Browser      : IE; Chrome; Firefox
Management Software      : Smart PSS Lite; DSS; DMSS
Mobile Client      : iOS;Android
Security      : Digest;security logs;HTTPS;trusted upgrade;WSSE;trusted boot;account lockout;generation and importing of X.509 certification;video encryption

Certifications      : CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power Supply      : 12 VDC (±30%); PoE (802.3af)
Power Consumption       : Basic: 2 W (12 VDC); 2.9 W (PoE) Max. (H.265 + intelligence on+ WDR + illuminator intensity): 4.6 W (12 VDC); 5.7 W (PoE)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : ≤95%
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : ≤95%
Protection      : IP67

Casing Material      : Inner core: Metal+plastic Cover: Plastic
Product Dimensions      : 100.9 mm × Φ109.9 mm (3.97″ × Φ4.33″)
Net Weight      : 0.33 kg (0.73 lb)
Gross Weight      : 0.45 kg (0.99 lb)
