Image Sensor      : 1/2.9″ CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
ROM      : 128 MB
RAM      : 256 MB
Scanning System      : Progressive
Electronic Shutter Speed      : Auto/Manual 1/3 s–1/100,000 s
Min.Illumination      : 0.0002 lux@F1.0
S/N Ratio      : >56 dB
llumination Distance      : Up to 50 m (164.04 ft) (Warm light)
Illuminator On/Off Control      : Auto;Manual
lIlluminator Number      : 4 (Warm light)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 2.8 mm; 3.6 mm; 6 mm
Max. Aperture      : F1.0
Field of View      : 2.8 mm: H: 101°; V: 53°; D: 119°, 3.6 mm: H: 81°; V: 44°; D: 95°, 6 mm: H: 53°; V: 29°; D: 61°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 1.1 m (3.61 ft), 3.6 mm: 1.7 m (5.58 ft), 6 mm: 3.4 m (11.15 ft)
DORI Distance      : Lens 2.8mm, Detect: 47.1m(154.53 ft), Observe: 18.9m(62.01 ft), Recognize: 9.4m(30.84 ft), Identify: 4.7m(15.42 ft) / Lens 3.6mm, Detect: 55.7m(182.74ft), Observe: 22.3m(73.16 ft), Recognize: 11.1m(36.42 ft), Identify: 5.6m(18.37 ft) / 6mm, Detect: 85.7m(281.17ft), Observe: 34.3m(112.53 ft), Recognize: 17.1m(56.10 ft), Identify: 8.6m(28.22 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

IVS (Perimeter Protection)     : Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human);
SMD      : SMD Plus
Smart Search      : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video Compression      : H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec      : Smart H.265+; Smart H.264+
Video Frame Rate      : Main stream: 1920 × 1080@(1–25/30 fps), Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability      : 2 streams
Resolution      : 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control      : VBR;CBR
Video Bit Rate      : H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps
Day/NightAuto      : Color/B/W
BLC      : Yes
HLC      : Yes
WDR      : 120 dB
White Balance      : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control      : Auto/Manual
Noise Reduction      : 3D NR
Motion Detection      : OFF/ON (4 areas, rectangular)
Region of Interest (RoI)      : Yes (4 areas)
Smart Illumination      : Yes
Smart Dual Light      : Yes
Image Rotation    : 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
Mirror      : Yes
Privacy Masking     : 4 areas
LDC      : Yes

Built-in Mic      : Yes, built-in Mic
Audio Compression      : G.711a; G.711Mu; PCM; G.726

Alarm Event      : No SD card; SD card full; SD card error; network disconnecton; IP conflict; illegal access; moton detecton; video tampering; tripwire; intrusion; SMD; voltage detecton; security excepton

Network Port      : RJ-45 (10/100 Base-T)
SDK and API      : Yes
Network Protocol      : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
Interoperability      : ONVIF (Profile S & Profile T); CGI
User/Host      : 20 (Total bandwidth: 48 M)
Storage      : FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser      : IE; Chrome; Firefox
Management Software      : Smart PSS Lite; DSS; DMSS
Mobile Client      : iOS;Android
Security      : Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning

Certifications      : CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;

Power Supply      : 12 VDC; PoE
Power Consumption       : Basic: 1.5 W (12 VDC); 1.9 W (PoE); Max. : 5.3 W (12 VDC); 6.3 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : ≤95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : ≤95% (RH), non-condensing
Protection      : IP67
Anti-corrosion Level      : Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Casing Material      : Metal
Product Dimensions      : 197.9 mm × 80.2 mm × 76.2 mm (7.79″ × 3.16″ × 3.00″)
(L×W×H)
Net Weight      : 0.56 kg (1.23 lb)
Gross Weight      : 0.71 kg (1.57 lb)
