Image Sensor      : 1/2.8″ CMOS
Max. Resolution      : 1920 (H) × 1080 (V)
Scanning System      : Progressive
ROM      : 128 MB
RAM      : 128 MB
Scanning System      : Progressive
Electronic Shutter Speed      : Auto/Manual 1/3 s–1/100,000 s
Min.Illumination      : 0.002 lux@F1.5 (Color, 30 IRE);, 0.0002 lux@F1.5 (B/W, 30 IRE);, 0 lux (Illuminator on)
S/N Ratio      : >56 dB
llumination Distance      : Up to 60 m (196.85 ft) (IR LED)
Illuminator On/Off Control      : Auto;Manual
lIlluminator Number      : 4 (IR LED)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°

Lens Type      : Motorized vari-focal
Lens Mount      : φ14
Focal Length      : 2.7 mm–13.5 mm
Max. Aperture      : F1.5
Field of View      : H: 108°–30°;, V: 56°–17°;, D: 131°–35°
Iris Control      : Fixed
Close Focus Distance      : 0.8 m (2.62 ft)
DORI Distance      : Lens W, Detect: 44.1m(144.69 ft), Observe: 17.7m(58.07 ft), Recognize: 8.8m(28.87 ft), Identify: 4.4m(14.4 ft) / Lens T, Detect: 144.8m(475.07ft), Observe: 57.9m(189.96 ft), Recognize: 29.0m(96.14 ft), Identify: 14.5m(47.57 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

IVS (Perimeter Protection)      : Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD      : SMD Plus
Smart Search      : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video Compression      : H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec      : Smart H.265+; Smart H.264+
Video Frame Rate      : Main stream: 1920 × 1080@(1–25/30 fps), Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability      : 2 streams
Resolution      : 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control      : CBR/VBR
Video Bit Rate      : H.264: 32 kbps–4096 kbps;, H.265: 12 kbps–4096 kbps
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : Yes
HLC      : Yes
WDR      : 120 dB
White Balance      : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control      : Manual;Auto
Noise Reduction      : 3D NR
Motion Detection      : OFF/ON (4 areas, rectangular)
Region of Interest (RoI)      : Yes (4 areas)
Smart Illumination      : Yes
Image Rotation    : 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
Mirror      : Yes
Privacy Masking     : 4 areas

Built-in Mic      : Yes, built-in Mic
Audio Compression      : G.711a; G.711Mu; G.726; PCM

Alarm Event      : No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; external alarm; SMD; security exception

Network Port      : RJ-45 (10/100 Base-T)
SDK and API      : Yes
Network Protocol      : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Interoperability      : ONVIF (Profile S & Profile T); CGI
User/Host      : 6 (Total bandwidth: 24 M)
Storage      : FTP; Micro SD card (support max. 256 GB)
Browser      : IE; Chrome; Firefox
Management Software      : Smart PSS; DSS; DMSS
Mobile Client      : iOS;Android
Security      : Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade

Certifications      : CE-LVD: EN62368-1;, CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Audio Input       : 1 channel (RCA port)
Audio Output      : 1 channel (RCA port)
Alarm Input      : 1 channel in : wet contact, 5 mA 3–5 VDC
Alarm Output      : 1 channel out: wet contact, 300 mA 12 VDC

Power Supply      : 12 VDC; PoE (802.3af)
Power Consumption      : Basic: 2W (12 VDC); 2.6 W (PoE), Max. (H.265+intelligence on +WDR +IR on): 8.6 W (12 VDC); 9.9 W (PoE)

Operating Temperature      : –30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity      : <95%
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Protection      : IP67; IK10 (optional)

Casing Material      : Metal + Plastic
Product Dimensions      : 239.2 mm × 90.7 mm × 90.7 mm (9.42″ × 3.57″ × 3.57″) (L×W× H)
Net Weight      : 0.79 kg (1.74 lb)
Gross Weight      : 1.05 kg (2.31 lb)
