Image Sensor      : 1/2.9″ CMOS
Max. Resolution      : 2560 (H) × 1440 (V)
ROM      : 128 MB
RAM      : 128 MB
Scanning System      : Progressive
Electronic Shutter Speed      : Auto/Manual 1/3 s–1/100,000 s
Min.Illumination      : 0.03 lux@F2.0 (Color, 30 IRE), 0.003 lux@F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
S/N Ratio      : >56 dB
llumination Distance      : Up to 30 m (98.43 ft) (IR)
Illuminator On/Off Control      : Auto;Manual
lIlluminator Number      : 1 (IR LED)
Angle Adjustment      : Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°

Lens Type      : Fixed-focal
Lens Mount      : M12
Focal Length      : 3.6 mm; 2.8 mm
Max. Aperture      : F2.0
Field of View      : 2.8 mm: H: 95°; V: 53°; D: 110°, 3.6 mm: H: 78°; V: 43°; D: 92°
Iris Control      : Fixed
Close Focus Distance      : 2.8 mm: 0.9 m (2.95 ft), 3.6 mm: 1.3 m (4.27 ft)
DORI Distance      : Lens 2.8mm, Detect: 61.6m(202.10 ft), Observe: 24.6m(80.71 ft), Recognize: 12.3m(40.35 ft), Identify: 6.2m(20.34 ft) / Lens 3.6mm, Detect: 76.0m(249.34 ft), Observe: 30.4m(99.74 ft), Recognize: 15.2m(49.87 ft), Identify: 7.6m(24.93 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Human Detection      : Support the classification and accurate detection of human
SMD      : SMD Plus
Smart Search      : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video Compression      : H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec      : Smart H.265+; Smart H.264+
Video Frame Rate      : Main stream: 2560 × 1440@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability      : 2 streams
Resolution      : 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control      : CBR/VBR
Video Bit Rate      : H.264: 32 kbps–4096 kbps;, H.265: 12 kbps–4096 kbps
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : Yes
HLC      : Yes
WDR      : 120 dB
White Balance      : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control      : Auto/Manual
Noise Reduction      : 3D NR
Motion Detection      : OFF/ON (4 areas, rectangular)
Region of Interest (RoI)      : Yes (4 areas)
Smart Illumination      : Yes
Smart Dual Light      : Yes
Image Rotation    : 0°/180°
Mirror      : Yes
Privacy Masking     : 4 areas

Built-in Mic      : Yes, built-in Mic
Audio Compression      : G.711a; G.711Mu; PCM; G.726

Alarm Event      : No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human)

Network Port      : RJ-45 (10/100 Base-T)
SDK and API      : Yes
Network Protocol      : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Register
Interoperability      : ONVIF (Profile S & Profile T); CGI
User/Host      : 6 (Total bandwidth: 24 M)
Storage      : FTP; Micro SD card (support max. 256 GB)
Browser      : IE; Chrome; Firefox
Management Software      : Smart PSS Lite; DSS; DMSS; DoLynk Care
Mobile Client      : iOS;Android
Security      : Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade

Certifications      : CE-LVD: EN62368-1;, CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power Supply      : 12 VDC/PoE (802.3af)
Power Consumption       : Basic: 2.1 W (12 VDC); 2.7 W (PoE); Max.: 4.4 W (12 VDC); 4.9 W (PoE) (H.265 + intelligence on + WDR+ IR intensity)

Operating Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity      : <95% (RH), non-condensing
Storage Temperature      : –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity      : <95% (RH), non-condensing
Protection      : IP67

Casing Material      : Metal + Plastic
Product Dimensions      : 180.4 mm × 70 mm × 70 mm (7.10″ × 2.76″ × 2.76″) (L×W×H)
Net Weight      : 0.31 kg (0.68 lb)
Gross Weight      : 0.42 kg (0.93 lb)
