Image Sensor      : 1/2.8″ CMOS
Pixel      : 4MP
Max. Resolution      : 2560 (H) × 1440 (V)
ROM      : 128 MB
RAM      : 128 MB
Electronic Shutter Speed      : 1 s–1/30,000 s
Scanning System      : Progressive
Min.Illumination      : 0.05 lux@F1.6 (Color, 30 IRE); 0.005 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on);
llumination Distance      : 30 m (98.43 ft) (IR + warm light-only warm light is enabled) 30 m (98.43 ft) (IR + warm light-only IR is enabled)
Illuminator On/Off Control      : Manual; auto; off
lIlluminator Number      : 2 (IR + warm light)

Focal Length      : 3.6 mm; 2.8 mm
Max. Aperture      : F1.6
Field of View      : 2.8 mm: H: 94°; V: 51°; D: 110°, 3.6 mm: H: 78°; V: 42°; D: 92°
Close Focus Distance      : 2.8 mm: 1.2 m (3.93 ft), 3.6 mm: 1.5 m (4.92 ft)
Iris Control      : Fixed
DORI Distance      : Lens 2.8mm, Detect: 56.0m(183.73 ft), Observe: 22.4m(73.49 ft), Recognize: 11.2m(36.75 ft), Identify: 5.6m(18.37 ft) / Lens 3.6mm, Detect: 72.0m(236.22 ft), Observe: 28.8m(94.49 ft), Recognize: 14.4m(47.24 ft), Identify: 7.7m(25.26 ft)

*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Pan/Tilt Range      : Pan: 0° to 345°; Tilt: 0° to +90°
Manual Control Speed      : Pan: 0.1°–37.66°/s; Tilt: 0.1°–32.61°/s
Preset Speed      : Pan: 0.1°–37.19°/s; Tilt: 0.1°–30.82°/s
Preset      : 50
Power-off Memory      : Yes
Idle Motion      : Preset;home position(only supports setting on DMSS)
PTZ Locked      : YES

IVS      : Yes
Human Detection      : Yes
Vehicle Detection      : Yes

Light Warning      : Warm light warning; Flash duration: 5 s–30 s; Flash frequency: high, medium, low
Sound Warning      : supports importing custom voice content;Sound can be set from 0%–100%. Play times can be set from 1-10.

Video Compression      : Smart H.265+;H.265;Smart, H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1)
Streaming Capability      : 2 streams
Resolution      : 4M (2560 × 1440);1080p (1920 × 1080); 720p (1280 × 720); 640 × 360 (640 × 360); QVGA (320 × 240)
Video Frame Rate      : Main stream: 1080p/720p/640 × 360@(1–25/30 fps)
Sub stream 1: 640 × 360/QVGA@(1–25/30 fps)
Bit Rate Control      : CBR/VBR
Video Bit Rate      : H264: 16 kbps–8,192 kbps, H265: 6 kbps–8,192 kbps
Day/NightAuto      : Auto(ICR)/Color/B/W
BLC      : Yes
WDR      : 120 dB
HLC      : Yes
White Balance      : Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Gain Control      : Auto/Manual
Noise Reduction      : 2D NR; 3D NR
Motion Detection      : Yes
Region Of Interest (Rol)      : Yes
Defog      : Electronic
Image Rotation      : 180°
Privacy Masking     : 4 area
S/N Ratio      : ≥55 dB

Audio Compression      : PCM; G.711A; G.711Mu; G.726
Built-in Mic      : Yes
Built-in Speaker      : Yes

Network Port      : RJ-45 (10/100 Base-T)
Network Protocol      : HTTP;HTTPS;TCP/ IP;IPv4;RTSP;UDP;DHCP;DNS;DDNS;IPv6;SSL;ARP;RTCP; RTP;IP Filter
Interoperability      : CGI;SDK;ONVIF (Profile S & Profile T)
Streaming Method      : Unicast/Multicast
User/Host      : 20 (total bandwidth: 64 M)
Storage      : FTP
Browser      : IE: IE 7 and later versions; Chrome; Firefox; Safari
Management Software      : Smart PSS;DMSS;Player;ConfigTool;NVR;Smart Player
Mobile Client      : iOS;Android

Abnormal Sound Alarm      : Yes

Certifications      : EN 62368-1;EN 55032;EN 61000-3-3;EN IEC 61000-3-2;EN 50130-4;EN 55035;

Audio Input      : 1 channel (built-in mic)
Audio Output      : 1 channel (built-in speaker)
Alarm Linkage      : Capture; preset; recording; audio; sending email
Alarm Event      : Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection;

Power Supply      : 12 VDC, 1.0 A ± 10%, PoE (802.3af)
Power Consumption       : 12 VDC, 1.0 A ± 10%: Basic: 3 W; Max: 11 W (illuminator+speaker+PTZ operation) PoE（802.3af Basic: 4 W; Max: 12 W (illuminator+speaker+PTZ operation)
Power Adapter      : Optional

Operating Temperature      : –30 °C to +55 °C (–22 °F to +131 °F)
Operating Humidity      : ≤95%
Protection      : IP66;TVS 2000 V lightning proof; surge protection; voltage transient protection

Product Dimensions      : 128.4 mm × Φ127.3 mm (5.06″ × Φ5.01″)
Net Weight      : 0.41 kg (0.9 lb)
Gross Weight      : 0.5 kg (1.1 lb)

* The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model
